| Engine Type | 2-stroke, single cylinder, air cooled |
|---|---|
| Displacement | 4.7 cu in (76.5 cc) |
| Engine Speed Max | 11,500 +/- 500 rpm (max) |
| Engine Speed Idle | 2,800 - 3,200 rpm |
| Fuel Mix Ratio | 50:1 (2%) fuel-to-oil |
| Fuel Capacity | 0.23 gal (0.88 L) |
| Power Type | Gas |
|---|---|
| Use Application | Asphalt Brick Block Concrete Masonry Stone |
| Weight, Saw Only | 21 lbs (9.6 kg) |
| Cutting Depth | up to 14 in (35 cm) |
| Bar Length | 12 in (30 cm) 14 in (35 cm) |
| Noise Level (Power, LWA) | 117 dB(A), (Kwa=3.0 dB(A)) |
| Chain Length | 12 in (30 cm) 14 in (35 cm) |
| Noise Level (Pressure, LpA) | 101 dB(A), (K=2.0 dB(A)) |
| Horsepower | 5 hp (3.7 kW) |
| Front Handle Vibration, ahv eq Concrete Cutting | 7.2 m/s2 (K=1.0 m/s2) |
| Rear Handle Vibration, ahv eq Concrete Cutting | 8.5 m/s2 (K=1.0 m/s2) |
| Water Supply (Min) | 20 psi (1.4 bar) |
| Water Flow Req (Min) | 2 gpm (8 lpm) |
| Unit of Measure | Each |
|---|
